CMOS image sensors (CIS) are widely adopted in many application fields, such as industry control system, automotive, consumer electronics, surveillance system, and so on.

Having an accurate and reliable model for electron generators is important when it comes to design of blocks dealing with elements such as photodiodes (PD) or ISFETs. Common way to simulate/analyse this type of blocks is to replace the photo diode with a current source. This may result in some unrealistic voltage developments on sensitive nodes or leakages not expected. Recent advances in photo-sensors field brings the need for an appropriate PD model under the spotlight.

Time-to-first-spike is an encoding scheme for a set of sensors, such as image pixels. Used to encode local contrast in an image sensor it can reduce data traffic and thus power consumption, as well as reduce latency for object recognition tasks.

Simulation is the most important method for verifying correct operation of electronics during the design phase. However, developing and using efficient simulation tools that are both accurate and fast, becomes an increasing challenge as circuits increases from thousands to billions of transistors. A possibility is to have several different types of description of the same module and toggle between these depending on needs. In this way we may toggle between more accurate (and slower) representations, and faster (and less accurate) representations depending on what is our requirements.

This project wants to explore possibilities to read out pixel data of a CMOS image sensor (CIS) non-destructively (i.e. without emptying the pixel of its photo charge) while the exposure is still ongoing. This will allow adaptive exposure time (or the adjustment of other exposure parameters) 'on the fly' leading to better quality images, without having to retake the image multiple times and thus wasting precious time in high speed applications.

Through the EU-funded 3D-MUSE project, we can design in one of the most advanced CMOS technologies available. We also get a taste of technologies that will not be widely available until a few years from now. Within this project, the ASIC design company Ideas together with IFI want to offer a master project where some key elements for a sensor system shall be designed.

'Multi-Needle Langmuir Probes' (MNLP) measure electron density in plasma on various space probes, e.g. on the ICI rocket series. The first task of the electronics (i.e. the sensor front-end (FE)) to read out the measuremnts is to power the sensor and amplify the sensing signal current. This project aims at implementing a new version of this FE as application specific integrated circuit (ASIC) in a specific 180nm CMOS technology.

CMOS image sensors (CIS) are widely adopted in various applications for example mobile and automotive cameras. As the application expanding their functionality to motion sensing and autonomous driving, the applications keep demanding for higher resolution and faster operating CIS while maintaining the power budget. Therefore, implementing CIS with low-noise and low-power analogue front end (AFE) is essential. Moreover, in an advanced process, conventional analogue design approaches have many challenges such as lower intrinsic gain of devices, and smaller headroom for operation. Therefore, a new structure is highly required to meet the requirements and to solve the challenges. A current-reusing architecture, as the name self-explained, utilizes the supply current to generate transconductance of both PMOS and NMOS. Therefore, the structure could improve gain, bandwidth, and noise characteristics comparing to the conventional analogue stages. For this reason, architecture is a suitable candidate for the solution.
